Multipurpose modular universal boxes are made for montage on the pole, in the wall, on the wall, freestanding with ground base, and freestanding
with underground base. It is made from pressed non-burning polyester, reinforced with glass fibers. It is resistant to strokes, bending and has high dialectical strength. Boxes are also resistant to weather conditions, as well as UV-rays. They have no harmful effect to the surroundings and can be completely recycled. They provide good mechanical and electrical protection and they fall under highly insulated boxes. By adding gasket rubber on doors, windows and other holes high degree of sealing IP 54 is achieved.
It is intended for circuits in measuring and distribution enclosures. Bearing is made of high quality imported plastic mass, self-extinguishing V-0 and heat resistance to 110°C without deformation. Contacts are made of brass profile which makes possible simultaneous connection of aluminum and copper.
Insulatedd waterproof clamp for switching from non-insulated conductors to lv abc-nf 2,5-150
It is used for connecting branching line of LV ABC to non-insulated Aluminium conductor. The clamp's body is made of Polyamid with fiber glass and it is resistant to all atmospheric and mechnaical conditions. Contact bridges are made of Aluminium alloy. Contact with branching conductors is made with the help of spikes for piercing the insulation, and the contact with the non-insulated conductors is made with the help plate to ensure high conductivity.
